LC1-PC20G6-6-IN-20 W- Premium Sound Ceiling Loudspeaker

Product Description

The LC1-PC20G6-6-IN premium ceiling speaker is a circular shaped, ABS material ceiling loudspeaker and has full-range performance in the bandwidth of 70 Hz to 20 kHz. It comes with a poly cone tweeter for enhanced performance.
The speaker has a line matching transformer to connect to a 100V output from an amplifier. The loudspeaker has power tappings at full power (20W), half power (10W), and quarter power (5W) and 1/8th power (2.5W) to connect at different power levels.
The LC1-PC20G6-6-IN premium ceiling speaker model ceiling speaker is for direct connection to a 100 V line output and is finished in white (RAL 9003) color.
The ceiling loudspeaker comes with a 100 V transformer with taps on the primary winding to allow different power tappings.
Nominal full-power, half-power or quarter-power radiation (in 3 dB steps) can easily be selected by connecting the amplifier output to the appropriate tapping.
All Bosch loudspeakers are designed to withstand operating at their rated power for 100 hours in accordance with IEC 60268-1 and IEC 60268-5 Power Handling Capacity (PHC) standards.
Bosch has also developed the Simulated Acoustical Feedback Exposure (SAFE) test to demonstrate that the speakers can withstand two times their rated power for short durations. This ensures extra reliability under extreme conditions, leading to greater customer satisfaction, longer operating life, and much less chance of failure or performance deterioration.
• 100 hours PHC (Powering Handling Capaclty) test in acc. to IEC 60268-1&5
• SAFE (Simulated Acoustic Feedback Exposure) test to withstand 50 sweep runs of square wave from low frequency to high frequency at twice the rated power, simulating feedback situation.

TECHNICAL SPECIFICATIONS

CEILING LOUDSPEAKER 20 W LC1-PC20G6-6-IN
