Send InquiryLBB 1956 00 Plena Voice Alarm Call Station
Product Details:
- Wireless No
- Weight (kg) 1 Kilograms (kg)
- Dimension (L*W*H) 40 x 100 x 235 Millimeter (mm)
- Color Charcoal with silver
- Warranty 1 Year
38500 INR/Unit
X
LBB 1956 00 Plena Voice Alarm Call Station Price And Quantity
- 38500 INR/Unit
- 1 Unit
LBB 1956 00 Plena Voice Alarm Call Station Product Specifications
- No
- 1 Year
- 40 x 100 x 235 Millimeter (mm)
- Charcoal with silver
- 1 Kilograms (kg)
LBB 1956 00 Plena Voice Alarm Call Station Trade Information
- 3-4 Unit Per Day
- 3-4 Days
- South India
Product Description
Each call station supports six zone selections. The number of selectable zones or zone groups can be increased by connecting call station keypads (LBB 1957/00). Up to eight keypads can be added with each keypad adding seven zone or zone-group keys.This call station features selectable gain, a selectable speech filter, and a limiter for improved intelligibility.The call station has a balanced line level output, making it possible to position it up to 1000 meters from the controller, using CAT-5 extension cables. With shielded cable, the call station can also be used in an EMC level 5 (heavy industry) environment.
DIP switches at the base of the Voice Alarm Call Station select different microphone gain levels, the call station ID, and the speech filter. A service accessible rotary control provides microphone level attenuation. LEDs on the call station show which zones have been selected. Three additional LEDs give visible feedback on the active state of the microphone and the system. Green flashing means standby (chime is sounding). Green indicates microphone active. Amber indicates that the system has detected a fault, and red indicates that the system is in the emergency state
TECHNICAL SPECIFICATIONS
LBB 1956/00 Plena Voice Alarm Call Station
| Power Supply voltage | 24 VDC supplied by LBB 1990/00 |
| Current consumption | <30 mA (plus <15 mA per keypad) |
| Nominal sensitivity | 85 dB SPL |
| Nominal output level | 700 mV |
| Input sound level (max) | 110 dB SPL |
| Input noise level (equiv.) | 25 dB SPLA |
| Frequency response | 100 Hz to 16 kHz |
| Output impedance | 200 ohm |
| Chimes Any wave file | Priorities 7 |
| Stem length with mic | 390 mm (15.35 in) |
| Distortion at rated output | <1% |
| Colour Front panel | Charcoal with silver |
| Operating temperature | -10Cto+45C |
| Storage temperature | -40Cto+70C |
| Relative humidity | <95% |
| Dimension | 40 x 100 x 235 mm |
| Weight Approx. | 1 kg |
